Introduction
Appliacation
Advantages:
Parameters:
| NO. | Parameter name/ | Parameter Value/ | Units of measurement/ | ||
| 1 | Basic parameters/ | ||||
| 1.1 | Working fluid/ | Oil | |||
| 1.2 | Nominal specified pressing force/ | 10÷60 | MN | ||
| 1.3 | Working table dimensions,not less than/ | ||||
| 1.3.1 | Length/ | 6000 | mm | ||
| 1.3.2 | Width/ | 2400 | mm | ||
| 2 | Slider/traverse | ||||
| 2.1 | Slider(or traverse)stroke | 3000 | mm | ||
| 2.2 | Slider(or traverse)movement accuracy in height | ±1 | mm | ||
| 2.3 | Allowable skew(misalignment)of the slider (movable traverse) | 0,5 | mm/running metre | ||
| 2.4 | Maximum distance between the table and the slider(movable traverse) | 5500 | mm | ||
| 2.5 | Allowable eccentricity at maximum force/ | 200 | mm | ||
| 2.6 | Allowable eccentricity at force of 20MN/ | 450 | mm | ||
| 2.7 | Press speed parameters in forging and die-forging (stamping)mode must be smoothly adjustable | ||||
| from 10%to maximum speed 100% | |||||
| Maximum speed of a slider(adjustable speed) | |||||
| 2.7.1 | during going down (idling stroke) | 300 | mm/sec | ||
| 2.7.2 | during the working stroke with maximum force(should be set)/ | 90 | mm/sec | ||
| 2.7.3 | during the working stroke with minimum force (should be set)/ | 180 | mm/sec | ||
| 2.7.4 | during going up/ | 300 | mm/sec | ||
| 3 | Table/ | ||||
| 3.1 | Stroke of the table in one direction from the middle of the press/ | 6000(towards the tools heating furnace） | mm | ||
| 3.2 | Maximum speed of table movement/ | 250 | mm/sec | ||
| 3.3 | Table movement accuracy/ | ±1 | mm | ||
| 3.4 | Number of fixed table positions (fixing device)/ | 3 | pcs | ||
| 3.5 | Number of side ejectors/ | 1/(from the exit side of the table) | pcs | ||
| 3.6 | Number of central ejectors/ | 1 | pcs | ||
| 3.7 | Number of tooling magazine positions(without tools heating)/（） | 4 | pcs | ||
| 3.8 | Ejector stroke/ | 1200 | mm | ||
| 3.9 | Max.adjustable ejector speed/ | 200 | mm/sec | ||
| 3.10 | Ejector force/ | 250 | ton | ||
| 4 | Forging parameters/ | ||||
| 4.1 | Target speed parameters:/ | ||||
| 4.1.1 | Working stroke speed of the press for forging with three cylinders(forging in the range of 45-60 MN)/ | 45-120 | mm/sec | ||
| 4.1.2 | Working stroke speed of the press for forging with two cylinders(forging in the range of 30-45 MN)/ | 150 | min/sec | ||
| 4.1.3 | Working stroke speed of the press for forging with one cylinder(forging in the range of 15-30 MN)/（15-30MN） | 180 | mm/sec | ||
| 4.1.4 | Speed of return stroke/ | 200 | mm/sec | ||
| 4.1.5 | Movement speed of moving table/ | 10-250 | mm/sec | ||
| 4.1.6 | Movement speed of tooling magazine/ | 10-250 | mm/sec | ||
| 4.2 | Forging accuracy | ||||
| 4.2.1 | Forging accuracy along the X/Y axes of forging blank (measured hot between two forged ends of blank) | ±1,0 | mm | ||
Customize:
Can be customized according to customer requirements.
Delivery date and quality assurance policy:
Delivery time: 3-6 months.
Warranty period: 12 months
