Petrochemical pipe fittings Hydraulic press machine

Max Feeding size:
Power:
Capacity:
Product description: DAYI heavy forging technology is a leading professional YD-P Petrochemical pipe fittings Hydraulic press machine manufacturers. Equipped with professional factory, welcome to wholesale our higher performance cost YD-P series hydraulic press. YD-P series hydraulic machine is mainly used for petorchemical pipe hot pressing, rolling, bending forming, fitting, upsetting process. Also it can be used in metal materials press correction flanging, Craft.Also our products support customized 300~50000 tons for demand from aerospace, Electric vehicles, ships, high-speed rail, wind power, nuclear energy, composite, Ti alloy forging, household appliances, general industrial forging.Our hot sale products as below: 1.Heavy High Speed hot free Forging hydraulic press Machine. 2.High Speed Hot Stamping frame Hydraulic Press 3.Titanium alloy and superalloy forging hydraulic press 4.Composite Material Forming hydraulic press Machine. 5.Close Die or open Free Forging Hydraulic Press 6.Automatic End thickening upsetting hydraulic press Machine line7.Automotive semi-axle bidirectional axle extruder, Spindle Axle Beams used heavy hydraulic press.8.Petrochemical pipe fittings upsetting, valve and flange forging Hydraulic press machine production lines
INQUIRY EMAIL

1.Product description

DAYI heavy forging technology is one of the leading China YD-P Petrochemical pipe fittings Hydraulic press machine manufacturers equipped with professional factory, welcome to wholesale cheap YD-P hydraulic press, YD-P hydraulic press, four and frame column hydraulic press, hydraulic oil press machine, hydraulic stamping machine, hydraulic deep drawing press, frame type hydraulic servo press, frame type hydraulic deep stamping press from us.

2.Application

This series hydraulic machine is mainly used for petorchemical pieces of the hot pressing, rolls and bending forming process. Also it can be used in metal materials press-printing correction flan ging,etc.Craft.

3.Product model

Item		Unit	Petrochemical Pipe Fittings Hydraulic Press
Item		Unit	YD(F)-P -500	YD(F)-P -630	YD(F)-P -800	YD(F)・P -1000	YD(F)・P -1250	YD(F)-P -1500
Nominal capacity		KN	5000	6300	8000	10000	12500	15000
Slide stroke		mm	900	900	900	1000	1200	1200
Daylight Opening height		mm	1600	1600	1700	1800	2600	2800
Slide speed	Down	mm/s	150	150	150	150	150	150
	Pressing	mm/s	4~12	4~10	4~10	4~10	4~10	4~10
	Return	mm/s	120	120	120	120	120	120
Table area	L・R	mm	1600	1600	1800	2000	3000	3500
Table area	F・B	mm	1400	1400	1500	1500	2200	2650
Motor power		KW	44	50	55	65	70	82
Remark

Item		Unit	Petrochemical Pipe Fittings Hydraulic Press
Item		Unit	YD(F)-P -2000	YD(F)-P •2500	YD(F)-P -3000	YD(F)-P -4000	YD(F)-P -5000	YD(F)-P -6000
Nominal capacity		KN	20000	25000	30000	40000	50000	60000
Slide stroke		mm	1500	1800	2500	2000	2000	2500
Daylight Opening height		mm	3000	3200	3500	3500	3600	4000
Slide speed	Down	mm/s	150	150	150	150	150	150
	Pressing	mm/s	4~10	5~12	5~12	5~12	5~12	5~12
	Return	mm/s	120	120	150	120	120	120
Table area	L・R	mm	3500	3600	4000	4000	4000	6000
Table area	F・B	mm	2600	2800	3000	3000	3000	3500
Motor power		KW	110	150	180	255	310	355
Remark					Moving table

4.Features and advantages

· Moving bolster

· Digital display and control device as stroke, pressure and speed.

· Industry touching screen monitor.

· Oil heating or cooling device.

· Safety device for slide

5.Delivery date and quality assurance policy

Delivery period: 4-8 months

Warranty period: 12 months
