Automotive Hydraulic press machine

Tube end thickening hydraulic press

Max Feeding size:
Power:
Capacity:
Product description: Tube and Pipe fitting end thickening hydraulic press, Die forging hydraulic press,Die Hot forging hydraulic press molding stamping, powder forge hydraulic press machine,Die forging hydraulic press,Free forging hydraulic press,rolls and bending forming process Hydraulic press, differential half-axle gear and planetary gear forging press machine, straight helical gear forging blank, automobile connecting rod hot forging hydraulic machine, automobile hub bearing-inner+outer ring hot forging hydraulic machine
INQUIRY EMAIL

1.Product description

The purpose of thickening is mainly to ensure the strength of the steel pipe at the cross section of the pipe end lathe or the strengh of welding. The types of steel tube thickening are: external thickening, internal thickening and internal and external thickening.

2.Features and advantages

The thickening machine set consists of a thickening machine, an auxiliary machine and a heating system, the steel pipe is heated horizontally and the end is thickened. Each thickening machine has an independent hydraulic control system and electric operation buttons. The hydraulic control system adopts a two-way cartridge valve integrated system, which has reliable performance, compact structure and beautiful appearance. The whole unit has a general operating platform to control the machine set

3.Application

Pipe end thickening unit is mainly suitable for the thickening process of drill pipe or tubing.

4. Product model

Item		Unit	Petrochemical Pipe Fittings Hydraulic Press
Item		Unit	YD(F)-P -500	YD(F)-P -630	YD(F)-P -800	YD(F)・P -1000	YD(F)・P -1250	YD(F)-P -1500
Nominal capacity		KN	5000	6300	8000	10000	12500	15000
Slide stroke		mm	900	900	900	1000	1200	1200
Daylight Opening height		mm	1600	1600	1700	1800	2600	2800
Slide speed	Down	mm/s	150	150	150	150	150	150
	Pressing	mm/s	4~12	4~10	4~10	4~10	4~10	4~10
	Return	mm/s	120	120	120	120	120	120
Table area	L・R	mm	1600	1600	1800	2000	3000	3500
Table area	F・B	mm	1400	1400	1500	1500	2200	2650
Motor power		KW	44	50	55	65	70	82
Remark

Item		Unit	Petrochemical Pipe Fittings Hydraulic Press
Item		Unit	YD(F)-P -2000	YD(F)-P •2500	YD(F)-P -3000	YD(F)-P -4000	YD(F)-P -5000	YD(F)-P -6000
Nominal capacity		KN	20000	25000	30000	40000	50000	60000
Slide stroke		mm	1500	1800	2500	2000	2000	2500
Daylight Opening height		mm	3000	3200	3500	3500	3600	4000
Slide speed	Down	mm/s	150	150	150	150	150	150
	Pressing	mm/s	4~10	5~12	5~12	5~12	5~12	5~12
	Return	mm/s	120	120	150	120	120	120
Table area	L・R	mm	3500	3600	4000	4000	4000	6000
Table area	F・B	mm	2600	2800	3000	3000	3000	3500
Motor power		KW	110	150	180	255	310	355
Remark					Moving table

5. Delivery date and quality assurance policy

Delivery period: 3-6 months

Warranty period: 12 months

6. Contact us

For more details about our cheap high performance cost power press and hydraulic press machine tools with JIS 1 accuracy standard, welcome and feel free to contact us.
